Description
JBL MA7100HP 7.2-Channel Network A/V Receiver
The JBL MA7100HP 7.2-Channel Network A/V Receiver is engineered for home entertainment enthusiasts seeking uncompromised audio and video performance. Designed to deliver immersive surround sound, high-resolution video passthrough, and seamless wireless connectivity, this receiver becomes the command center for a high-end home theater setup.
Combining Dolby Atmos and DTS:X decoding, support for HDR10+ and Dolby Vision, and Class-D amplification, the MA7100HP ensures a cinematic experience right in your living room. With its ability to handle object-based audio configurations like 5.1.2, the receiver surrounds you with multidimensional sound, placing you at the center of the action.
Whether you’re watching blockbuster films, streaming high-fidelity music, or gaming with ultra-low latency, the JBL MA7100HP adapts to your environment and needs with professional-grade audio performance and future-ready connectivity.
JBL MA7100HP Receiver Key Specifications Table
| Feature | Specification |
|---|---|
| Channels | 7.2 / 7.1 / 5.1.2 Object-Based Audio |
| Amplifier Class | Class-D |
| Power Output per Channel | 125W @ 8 Ohms (0.5% & 1% THD), 175W @ 4 Ohms (0.5% THD) |
| DTS Compatibility | DTS:X |
| Dolby Compatibility | Dolby Atmos |
| HDR Support | Yes, HDR10+, Dolby Vision |
| Video Upscaling | No |
| Rear HDMI Inputs | 6x HDMI 2.1 |
| Rear A/V Inputs | Optical TOSLINK, Digital Coaxial, Phono RCA, Stereo RCA x2 |
| Rear A/V Outputs | 1x Stereo RCA (Zone 2), 2x RCA Subwoofer |
| Front I/O | None |
| Wireless Connectivity | Wi-Fi, Bluetooth 5.3 LE |
| Wireless Audio Support | AirPlay 2, Chromecast built-in |
| Audio Codecs Supported | aptX Adaptive, aptX HD |
| Control App | Not Supported |
| HDCP Version | 2.3 |
| ARC Support | eARC |
| HDMI CEC | Yes |
| Bi-Amp Capability | Yes |
| Power Input | 110–240V AC, 50/60Hz |
| Max Power Consumption | 700W |
| Standby Power Consumption | 0.5W |
| Dimensions (W x H x D) | 17.0 x 5.3 x 15.6 inches |
| Weight | 16.3 lb (7.4 kg) |
Features of the JBL MA7100HP
-
7.2 Channel Surround Sound with 5.1.2 Object-Based Audio
Supports Dolby Atmos and DTS:X for immersive audio with ceiling channel simulation and multidirectional soundstage. -
High Power Output
Delivers up to 175W per channel at 4 Ohms, ensuring clean and dynamic amplification for demanding speakers. -
Next-Gen HDMI 2.1 Connectivity
Six rear HDMI 2.1 inputs allow passthrough of ultra-high definition content, making it compatible with 4K and 8K sources, gaming consoles, and streaming devices. -
Dolby Vision and HDR10+ Support
Unlocks vivid, high-contrast visuals with metadata-driven HDR formats that enhance your visual experience. -
Wi-Fi and Bluetooth 5.3 LE
Stream music wirelessly from mobile devices with low-latency, high-fidelity Bluetooth and Wi-Fi compatibility. -
Advanced Wireless Audio Support
Supports aptX Adaptive and aptX HD for wireless high-resolution audio. Features AirPlay 2 and Chromecast built-in for multi-room streaming. -
eARC and HDMI CEC
Enjoy simplified connection and audio sync between devices. Enhanced Audio Return Channel (eARC) enables uncompressed audio formats from compatible TVs. -
Multi-Zone Audio Support
Includes Zone 2 RCA output for distributing audio to a second room or zone without additional equipment. -
Bi-Amp Capability
Drive high- and low-frequency speaker elements separately for enhanced clarity and detail in sound reproduction. -
Efficient Class-D Amplification
Provides high-efficiency power delivery with lower heat output, ideal for compact installations and extended use. -
Flexible Input Options
Includes phono input for turntables, coaxial, optical, and RCA connections to support a wide range of legacy and modern devices.
Immersive Home Theater Experience
The JBL MA7100HP delivers a premium home theater experience with Dolby Atmos and DTS:X, bringing spatial realism to your audio environment. Whether you’re watching a movie with rain falling above you or a car chase zooming around you, the object-based audio formats place sound exactly where it should be.
Paired with its 5.1.2 configuration, this receiver enables dedicated height channels without needing a full-blown ceiling speaker setup. This makes it ideal for modern living spaces that demand high performance in a flexible, space-efficient package.
Audiophile-Grade Performance
With up to 175 watts per channel at 4 ohms, the JBL MA7100HP is capable of driving even power-hungry speakers with ease. Its Class-D amplification ensures low distortion, wide frequency response, and energy efficiency. Audiophiles and casual listeners alike will appreciate the clarity, punch, and warmth in the sound signature.
Support for high-resolution wireless audio via aptX Adaptive, aptX HD, AirPlay 2, and Chromecast built-in ensures seamless streaming without sacrificing quality.
Smart Connectivity and Future-Proof Design
Featuring six HDMI 2.1 inputs, the MA7100HP supports cutting-edge gaming consoles and high-definition media players. Even without video upscaling, its HDR10+ and Dolby Vision passthrough guarantees stunning visuals with deep blacks and vibrant highlights.
With eARC, HDCP 2.3, and HDMI CEC, your system is well-integrated with modern TV technology, ensuring minimal audio delay, proper format support, and easy device synchronization.
Built to Integrate Effortlessly
Despite its advanced feature set, the JBL MA7100HP remains user-friendly. Its graphical user interface (GUI) ensures intuitive setup and management, even for users new to home AV systems.
Its design allows bi-amping, supports multiple speaker layouts, and provides Zone 2 outputs for flexible audio distribution. Phono and digital inputs make it easy to plug in classic turntables or modern media players.
Compact Yet Powerful
At just 5.3 inches high and 16.3 lbs, the JBL MA7100HP is sleek enough to integrate into compact home entertainment racks without sacrificing power. The power-efficient Class-D amplifier helps manage heat generation, making it ideal for media cabinets and continuous use scenarios.
Conclusion
The JBL MA7100HP 7.2-Channel Network A/V Receiver represents the next generation of home theater technology. With support for object-based audio, high dynamic range video, modern wireless protocols, and high-efficiency amplification, it is an exceptional centerpiece for any entertainment setup.
